Process Equipment ⟩ Products + Services ⟩ Pumps ⟩ Positive Displacement Pumps ⟩ AODD ⟩ 2:1 Ratio High Pressure Pump

2:1 Ratio High Pressure Pump

Air-Operated Double Diaphragm Pumps, also known as AODD pumps provide high performance, reliable solutions for your pumping needs.

2:1 Ratio High Pressure Pump

  • Robust construction, easy to maintain
  • Can easily handle viscous, high SG and high head applications
  • Smooth action, less vibration and wear
  • Port sizes from 1 ½” to 3”
  • Pressures up to 13.8 bar
  • Available in a wide range of materials
  • Flow rates up to 605 litres/minute
  • Bolted construction for greater integrity
  • Reliable pneumatic air valve
  • Stalls against closed head without damage
  • Re-start on demand
2:1 Ratio High Pressure

Overview

The ARO high pressure air diaphragm pump was developed for applications requiring fluid pressures in excess of the 100 psi allowed by traditional pumps. Compared to a standard diaphragm pump, our 2:1 ratio high pressure diaphragm pump can produce up to 200 psi at about half the flow rate.
The 2:1 ratio is accomplished by using the effective surface area of both diaphragms to double the output pressure.

Features

  • Utilizing Power – Can produce up to 200 psi, at about half the flow rate of a standard diaphragm pump. Our high pressure air operated diaphragm pump utilizes the effective surface areas of both diaphragms to double output pressure.
  • Structural Integrity – Bolted construction eliminates problems associated with leaking band-clamps while also reducing maintenance costs.
  • Simul-Shift™ and Quick Dump™ valve technology for stall free and ice free operation
  • Intelligent Design – Modular major valve design for easy repair and maintenance
  • Built to Last – Convoluted diaphragms for long life
  • Size – Available in 3″, 2″ and 1.5″ port sizes
